2003-2009 Nissan 350Z

Change to kinetix????

Old 04-15-2019, 06:15 AM
  #1
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default Change to kinetix????

Hello all, I have a FBO 03 350z 6spd. I just had jwt s1 cams installed. Right now Iím in the fence about the kinetix velocity manifold, Iíve read to many different stories from heck ya, to nope, in some cases it actually losses power. I havenít got it back on the dyno yet to measure the gains (made prior 283 local tuner before cams). Wonít until, I install the manifold or just leave alone. From what I see, the manifold seems to really hold the power at the very top...... with the cams I see that helping even more now. But at 700+ bucks itís not a for sure gain lol. Hereís what she has now.
MD shockwave
MD art pipes
5/16 spacer
admin tuning 3.5 intake with added velocity stack.
lightweight pulleys
short tube headers (unknown brand)
shift tech Ported upper plenum
shifttech version of mrev
ported oem TB 5mm
Mr600r is offline
Old 04-15-2019, 06:32 AM
  #2
bealljk
Registered User
iTrader: (13)

Join Date: Apr 2010
Location: North Denver
Posts: 3,918
Liked 395 Times in 334 Posts
Default

losses vs. loses

I would look what Conway has done on his setup. You two have similar setups and you indeed might benefit from the swap.

But yea, at $7 that's a heavy price for gains that you'll only see when your engine is at redline.

If I were in your shoes I would stick with what you have and spend the cash somewhere else.

Have you considered a turbo/supercharger?

If you want to stay NA and you HAVE to spend the cash maybe consider other performance enhancing mods such as lighter wheels, lightweight battery, clutch/flywheel upgrades.

Do you have any pictures of your setup?

Last edited by bealljk; 04-15-2019 at 06:34 AM.
bealljk is offline
Old 04-15-2019, 07:03 AM
  #3
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default

I did the cams and the change is phenomenal over stock cams. The car is dam fast now, guess Iím just tying maximize the NA part (dam close anyway). I havenít retuned either. Iím guessing another 8-10 from a retune???? Itís running off prior tune and parts prior to cams. Boost is in my thoughts, lol I canít even imagine that kind of power 400+. The cars gets ridiculous sideways as is with current power.
Mr600r is offline
Old 04-15-2019, 07:16 AM
  #4
RobPhoboS
Registered User

Join Date: Dec 2012
Location: UK
Posts: 341
Liked 28 Times in 25 Posts
Default

You 100% need to retune for many reasons, so get that done first (ideally on the dyno).
I personally ignore the numbers, use the same dyno for consistency and as long as the numbers improve in the area you want, lovely.

I'll be getting my Kinetix this week hopefully, I have the C8 cams, uprated oil pump, slightly higher rev limit.
I'll be getting another remap as well, so I'll see what happens with it, although I'll be getting ANOTHER remap after the PPE long tubes are installed too.

My car is used on track so power up the top is fine by me, which is what that Kinetix product seems to do (with complementing parts installed).

Your call. Your money
RobPhoboS is offline
Old 04-15-2019, 07:43 AM
  #5
bealljk
Registered User
iTrader: (13)

Join Date: Apr 2010
Location: North Denver
Posts: 3,918
Liked 395 Times in 334 Posts
Default

what Rob said...retune for sure - you'll probably open more than 8-10 up.
bealljk is offline
Old 04-15-2019, 07:44 AM
  #6
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default

Thatís right, I installed the rev up oem oil pump as well, my rpm was also raised to 7100 I believe. I wonít be on a road course (dam expensive down here) but I do drag race the car fairly often, and for this reason the higher rpm power will definitely help.........
Mr600r is offline
The following users liked this post: Mr600r
RobPhoboS (04-15-2019)
Old 04-15-2019, 07:48 AM
  #7
RobPhoboS
Registered User

Join Date: Dec 2012
Location: UK
Posts: 341
Liked 28 Times in 25 Posts
Default

I'll post up my results when I can get the remap done as well, whether it makes or loses power I'll show it.
There is some amazing information on this forum, it does get clouded sometimes by some grumpy folks arguing with each other but if you can sift through it, it's golden
RobPhoboS is offline
Old 04-15-2019, 08:12 AM
  #8
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default

Yes please post up your results! Iím very curious to see the curve
Mr600r is offline
The following users liked this post: Mr600r
RobPhoboS (04-15-2019)
Old 04-15-2019, 08:35 AM
  #9
RobPhoboS
Registered User

Join Date: Dec 2012
Location: UK
Posts: 341
Liked 28 Times in 25 Posts
Default

Originally Posted by Mr600r View Post
Yes please post up your results! Iím very curious to see the curve
Absolutely, as soon as I've fitted stuff and can get down there


Current curve is like this, please note this dyno over here reads much lower than others I have visited (which were just rolling road days, not tuning):




If you use this link, it's quite good for comparing against other readings:

http://mkiv.supras.org.nz/dyno.htm
RobPhoboS is offline
Old 04-15-2019, 10:05 AM
  #10
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default

Wow 310 RWHP! Sounds like u have quite a bit in the car to make that number?!!!!
Mr600r is offline
Old 04-15-2019, 10:34 AM
  #11
RobPhoboS
Registered User

Join Date: Dec 2012
Location: UK
Posts: 341
Liked 28 Times in 25 Posts
Default

Originally Posted by Mr600r View Post
Wow 310 RWHP! Sounds like u have quite a bit in the car to make that number?!!!!
I think it's 258rwhp, 310 fw (calculated).
That's why I say look at the converter to see a dyno you're more familiar with.
It'll change with the long tubes and kinetix again, so it's just the interim data for now.
RobPhoboS is offline
Old 04-15-2019, 12:20 PM
  #12
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default






Mr600r is offline
The following users liked this post: Mr600r
blufc3s (04-16-2019)
Old 04-15-2019, 02:27 PM
  #13
dnash
Registered User
iTrader: (1)

Join Date: Jun 2004
Location: Ontario, Canada
Posts: 86
Liked 1 Time in 1 Post
Default

I don't think you would see enough of a change with the Kinetix to justify the expense. Have you thought about rear gears, better diff, lightweight flywheel, upgraded clutch? None of these mods will make more HP but they will add to the fun factor for sure.
dnash is offline
Old 04-15-2019, 02:51 PM
  #14
Mr600r
Registered User
Thread Starter

Join Date: Feb 2017
Location: San Antonio
Posts: 37
Likes: 0
Liked 10 Times in 10 Posts
Default

My bad, I do have JWT light flywheel, stage 2 clutch........ forgot I had those as well 🤦🏻*♂️.
The car is plenty of fun, sinse I added the cams I was thinking itís a worthwhile expense... but not certain, why Iím here getting the opinions of you all.
the cams helped out the top end quite a bit. Hell all over, as expensive as they where the end results was very worth it to me... seems like most are leaning toward leaving alone and just retune......
Mr600r is offline
Old 04-15-2019, 03:22 PM
  #15
dnash
Registered User
iTrader: (1)

Join Date: Jun 2004
Location: Ontario, Canada
Posts: 86
Liked 1 Time in 1 Post
Default

Originally Posted by Mr600r View Post
My bad, I do have JWT light flywheel, stage 2 clutch........ forgot I had those as well 🤦🏻*♂️.
The car is plenty of fun, sinse I added the cams I was thinking itís a worthwhile expense... but not certain, why Iím here getting the opinions of you all.
the cams helped out the top end quite a bit. Hell all over, as expensive as they where the end results was very worth it to me... seems like most are leaning toward leaving alone and just retune......
I would definitely look into the rear gears then.
dnash is offline
Old 04-15-2019, 04:42 PM
  #16
DarkZ03
Registered User
iTrader: (11)

Join Date: Jun 2007
Location: Des Plaines
Posts: 541
Liked 34 Times in 30 Posts
Default

I have yet to regret buying mine, I mostly got it for looks and ease of use when taking stuff apart. I had a modded upper and lower with spacer and I honestly didn't feel a loss, I do have to tune it soon though.
DarkZ03 is online now
Old 04-15-2019, 05:04 PM
  #17
icer5160
Registered User
iTrader: (4)

Join Date: May 2010
Location: Mountain View, CA
Posts: 533
Liked 70 Times in 56 Posts
Default

As others have stated, I would recommend skipping over the Kinetix manifold. From the reading material I've come across regarding the Kinetix and Cosworth intake manifolds, they don't really shine unless you go FI. If you're sticking with an NA setup, the OEM plenum/manfiold or MREV are good options, if not better when considering the cost:gain ratio. Based on what I've read and heard by talking with my local tuning shop, you'd be really hard pressed to get an NA VQ35DE beyond 300rwhp (Although I've heard it can be done). This requires very aggressive cams, timing and fuel map tuning, as well as open exhaust & intake. The car would no longer pass inspection at the end of the day and idle like crap thanks to the overly aggressive cams. ITBs are pretty sweet, but again won't pass inspection and even more expensive. I've only heard of ITBs on Zs setup strictly for the track, not street.

Changing up the final drive gear ratio will certainly help improve acceleration. The only downside to this is you lose some accuracy in your speedo and sacrifice a little fuel economy (but who cares about that in a sports car anyway!). Otherwise you can try to find ways to remove weight from the vehicle. If you haven't already, look into the "pulley delete" since you have an 03. That will free up a little power and remove some weight. The touring V3 wheels you have are nice! But the rears are 19", if you want to maximize torque/power to the rear wheels and save some additional weight, look into a nice set of forged 18"s.

Here's a good article on a built NA VQ35DE (non-revup):
http://www.superstreetonline.com/how...-engine-build/

Here's what a track tuned Z with ITBs sounds like:

-Icer
icer5160 is offline
The following users liked this post: icer5160
bealljk (04-15-2019)
Old 04-15-2019, 10:10 PM
  #18
bealljk
Registered User
iTrader: (13)

Join Date: Apr 2010
Location: North Denver
Posts: 3,918
Liked 395 Times in 334 Posts
Default

If it was me and I had to spend $700 on something other than FI I would look to lighten the car up...

Icer - I like that they open that video up with RPF1s!
bealljk is offline
Old 04-16-2019, 12:57 AM
  #19
RobPhoboS
Registered User

Join Date: Dec 2012
Location: UK
Posts: 341
Liked 28 Times in 25 Posts
Default

icer5160:
I think you're partially wrong, there are threads showing them work properly with different cams, not just for FI cars.

Read this thread (not glossing over it, post #86 onwards if you want but its good throughout)
https://my350z.com/forum/intake-exha...intakes-5.html

Last edited by RobPhoboS; 04-16-2019 at 04:19 AM.
RobPhoboS is offline
The following users liked this post: RobPhoboS
icer5160 (04-16-2019)
Old 04-16-2019, 02:09 AM
  #20
DarkZ03
Registered User
iTrader: (11)

Join Date: Jun 2007
Location: Des Plaines
Posts: 541
Liked 34 Times in 30 Posts
Default

That's a shadow of the current engine that car is running, highest documented NA VQ at 500+ wheel
DarkZ03 is online now
The following users liked this post: DarkZ03
RobPhoboS (04-16-2019)
