Parking lights are some 1 led polarized bulbs from Superbrightleds, these are the only ones I've bought from this company that haven't burned out.
The LEDs in the reflectors are 5mm LEDs I mentioned earlier. They're running at 3.5 volts and 21 mA.
The LEDs in the reflectors are 5mm LEDs I mentioned earlier. They're running at 3.5 volts and 21 mA.
#29
Registered User
Join Date: Aug 2005
Location: Raleigh, NC
Posts: 24
Likes: 0
Received 0 Likes
on
0 Posts
The LEDs are placed towards the rear of the reflector in this case because the plastic and metal bracketry on the back on the reflector was difficult to modify. Since I moved them towards the rear, I angled the LEDs so that the light is more forward. This seems to allow the LEDs to be seen from the front a little better.
The wiring of the LEDS is similar to the illustration attached.
The wiring of the LEDS is similar to the illustration attached.
#32
Registered User
Plasmaled.com & autodirectsave.com have 5 mm & 8 mm led's for 12 volt parellell setup wiith the Resistors and wires already soldered up .. just wire up !! 10 for $12.00 ... all colors ..
#35
Registered User
Bought the 5 MM Led's From " Plasma Led.com " 10 for $12 .. they Have the Built in Leads and Resitors .. They Work Great fot The Side Reflectors, No Calculating or Extra Soldering ect.. Great ...Thank's.. Great Wright up !!
#36
Club Moderator
the Hot Spot
the Hot Spot
iTrader: (1)
Originally Posted by Agentman03
Bought the 5 MM Led's From " Plasma Led.com " 10 for $12 .. they Have the Built in Leads and Resitors .. They Work Great fot The Side Reflectors, No Calculating or Extra Soldering ect.. Great ...Thank's.. Great Wright up !!
#37
Registered User
iTrader: (17)
Join Date: May 2006
Location: WSU
Posts: 879
Likes: 0
Received 0 Likes
on
0 Posts
Alright I just went crazy tonight. Bought some clear reflectors from ebay. Bought 1000 red LED's from surplusleds.com for 40 bucks (Planning on making a few sets of these).
Determining whether or not to pull the trigger right now on some parking lights and the blinkers.
Anyone know if you have to open up the headlight to access the parking and blinker lights? I am assuming no but cant remember.
Determining whether or not to pull the trigger right now on some parking lights and the blinkers.
Anyone know if you have to open up the headlight to access the parking and blinker lights? I am assuming no but cant remember.
#38
Originally Posted by gNaRKiLL
Anyone know if you have to open up the headlight to access the parking and blinker lights? I am assuming no but cant remember.
1. remove the wheel.
2. remove the plastic inner fenderwell.
3. have fun.
