Default DIY: Vanity Mirror LED replacement under $5

Sick of the vanity incandescent lamps screwing up you crispy white lights inside your car? Here is a quick easy fix for that under $5.

Before:
Name:  f8f6b0ee.jpg
Views: 456
Size:  53.9 KB


Tools needed
Some type of pliers
Razor knife
Tiny screwdriver (flat head)
31mm Festoon style led bulb ebay link
2 yellow crimp on connectors (can be purchased at any automotive store)

Name:  d3aa5bf1.jpg
Views: 400
Size:  63.5 KB

1. Remove the existing incandescent bulb use the tiny screwdriver to pry off the lens and pop the bulb out (be careful not to touch both sides of the metal with said screwdriver or you could pop a fuse)

2. Pry off the ends of the festoon led bulb (one came right off the other I had to bend and break the plastic lens to get it)(be careful of the circuit board and resistor)

3. Once you have the circuit board removed should look like this:


4. Cut the yellow plastic off the connectors:


5. Cut the connector with the pliers:


6. You might have to take the screwdriver and open the end you cut off so the leads will fit in the gap.

7. Bend the leads towards the back at a right angle and put the connector right up to the circuit board with the lead in opening and squeeze it together just enough to squeeze the leads so won't fall out. (could solder for a stronger hold):


8: Repeat on the other side (be careful of resistor):




9. I had to slightly squeeze the prongs together to hold the led tightly. Lens can be a pita to put back on just take your time and don't force it.

10. Look at how bad of a job you did shaving and enjoy your crisp white lights.

After:
