Anyone have the wiring diagram for the tps system?
i have a feeling something is broken in the circuit and im gonna run an overlay if anything. Replaced the tb and the pedal sensor. Still going into limp mode after 10 minutes of driving. I saw in another thread that wheel size can throw it off. How true is that?



Attached is from the FSM. Hopefully you get it sorted out.



hey i checked trhe grounds and they all seem to be good. i just realized i changed the battery and that is when it started happening.do you think its possible that the battery is the route of the problem. i read on an old thread that the ecm and the throttle bodie circut is not fused and the guy replaced the ecm and it worked. should i try the battery first and then possibly an ecm?



It's up to you. Personally, I would try the cheapest route first to try and self-diagnose or fix it, and then take it to someone who knows what they're doing before just throwing parts at it.
